MCMASTER-CARR 加长固定螺钉18-8不锈钢 1/4"-20 螺纹92845A535
MCMASTER-CARR 加长固定螺钉18-8不锈钢 1/4"-20 螺纹92845A535
| Material | 18-8 Stainless Steel |
| Thread Size
|
1/4"-20
|
| Length | 3/8" |
| Tip | |
| Diameter | 0.156" |
| Diameter Tolerance | -0.007" to 0" |
| Length | 0.067" |
| Length Tolerance | -0.005" to 0" |
| Drive Size | 1/8" |
| Screw Size Decimal Equivalent | 0.250" |
| Hardness | Rockwell B80 |
| Specifications Met | ASME B18.3 |
| Thread Type | UNC |
| Thread Spacing
|
Coarse
|
| Thread Fit | Class 3A |
| Thread Direction | Right Hand
|
| Drive Style | Hex
|
| Tip Type | Extended |
| Head Type | Headless |
| System of Measurement | Inch |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (01/17/2022, 223 SVHC) Compliant |
| DFARS | Not Specialty Metals Compliant |
声明：无锡智泓科技有限公司作为进出口公司，诚意供应此产品，但绝非是该品牌在中国的代理、分公司以及办事处，请和我们一起守护诚信，拒绝虚假宣传。
