MCMASTER-CARR 销钉4037、4140合金钢 98381A502
MCMASTER-CARR 销钉4037、4140合金钢 98381A502
| Pin Type | Dowel |
| End Type | Plain |
| Head Type | Plain |
| Shaft Type | Plain |
| End Shape | Rounded × Chamfered |
| System of Measurement | Inch |
| Material | 4037 Alloy Steel, 4140 Alloy Steel |
| Length | 5/16" |
| Diameter | 3/16" |
| Diameter Tolerance | 0.0001" to 0.0003" |
| Min. Hardness | Rockwell C47 |
| Breaking Strength | 5,900 lbs. |
| Tolerance Rating | Standard |
| Specifications Met | ASME B18.8.2 |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (01/17/2022, 223 SVHC) Compliant |
| DFARS | Specialty Metals Compliant (252.225-7008) |
声明：无锡智泓科技有限公司作为进出口公司，诚意供应此产品，但绝非是该品牌在中国的代理、分公司以及办事处，请和我们一起守护诚信，拒绝虚假宣传。
